Clean Connection Cabinet JW-300-CCB Valve Manifold Box And Control Valve Box

Category:

Technical Data

Model JW-300-CCB
Physical dimension 2S: W856* D790* H1865 4S: W1050 * D790 * H1865, can be specially customized according to user requirements
Control cabinet power supply 220VAC, 50HZ, 25W, leakage protection
Purge PN2,SS316 1/2″SWG
Ultra-pure water UPW, JIS 16A bonding
Compressed air CDA,SS316 1/2″SWG
Waste outlet Drain,PP DN20 Fusion Socket
Cabinet ventilation OD 100MM,150m³/hr
Standard equipment PP shell+transparent PVC observation window+PFA internal pipe valve components, nitrogen blowing, pipeline pressure maintaining function before sampling and filling, leakage alarm, negative pressure alarm

Optional
*Barcode Reader
*Color touch screen
*Filters CDA&N2
*Pure water sampling
